Pe scurt
- Gross Horsepower (Maximum)
- 29.8 kw 40 hp
Caracteristici & beneficii
- Lightweight design (<750 kg)
- Standard turntable
- 7-in infeed capacity
- Double infeed rollers with offset
- Steel construction bonnet
Broșuri & fișe tehnice
Date tehnice
Specificații tehnice
| Length - Feed Table Up, Tongue In | 317.5 cm 125 in |
|---|---|
| Length - Table Down, Tongue Extended | 375.9 cm 148 in |
| Length - Tongue In | cm in |
| Length - Tongue Extended (Additional) | cm in |
| Width | 133.1 cm 52.4 in |
| Height | 231.1 cm 91 in |
| Weight (without winch and hydraulic jack) | kg lbs |
| Weight (with winch, hydraulic jack and hydraulic chute) | kg lbs |
| Weight with outriggers (additional) | kg lbs |
| Weight - Engine Option One | 744.8 kg 1642 lbs |
| Weight - Engine Option Two | kg lbs |
| Weight - Engine Option Three | kg lbs |
| Weight - Engine Option Four | kg lbs |
| Tongue Weight - Engine Option One | 69.9 kg 154 lbs |
| Tongue Weight - Engine Option Two | kg lbs |
| Tongue Weight - Engine Option Three | kg lbs |
| Length with Winch (Additional) | cm in |
| Weight With Winch (Additional) | kg lbs |
| Weight With Loader (Additional) | kg lbs |
| Weight With Steel Tracks (Additional) | kg lbs |
| Sound Power | 129 dB(A) |
| Sound Power - Engine Option Two | — |
| Sound Power - Engine Option Three | — |
| Horsepower Options | 40 hp |
| Make and Model | Briggs & Stratton 61G2 Vanguard EFI/ETC |
|---|---|
| Number of Cylinders | — 2 |
| Gross Horsepower (Maximum) | 29.8 kw 40 hp |
| Torque (Max) | 72.9 Nm 53.8 ft-lb |
| Fuel Tank Capacity | 26.5 L 7 gal |
| Max Fuel Consumption | 4.5 lph 1.2 gph |
| Fuel Type | Unleaded gasoline 95 Octane max 10% methanol |
| Air Cleaner | Donaldson 2 Stage Dry |
| Oil Filter | Spin on |
| Recommended Oil | Mobil SHC Hydraulic EAL 46 |
| Oil Volume with Filter | 3.1 L 3.3 qt |
| Maximum Angle of Continuous Operation | — 25 deg |
| Cooling Medium | Air |
| Coolant Capacity (Engine and Radiator) | L gal |
| Alternator | 5 Amps Briggs & Stratton |
| Fan | Integrated in engine |
| Clutch Type | Direct drive |
| Clutch Drive Engagement | Direct drive |
| Make and Model | — |
|---|---|
| Weight | kg lbs |
| Tongue Weight | kg lbs |
| Number of Cylinders | — — |
| Gross Horsepower (Maximum) | kw hp |
| Torque (Max) | Nm ft-lb |
| Fuel Tank Capacity | L gal |
| Max Fuel Consumption | lph gph |
| Fuel Type | — |
| Air Cleaner | — |
| Oil Filter | — |
| Recommended Oil | — |
| Oil Volume with Filter | L qt |
| Maximum Angle of Continuous Operation | — deg |
| Coolant Capacity (Engine and Radiator) | L gal |
| Cooling Medium | — |
| Alternator | — |
| Fan | — |
| Clutch Type | — |
| Clutch Drive Engagement | — |
| Make and Model | — |
|---|---|
| Weight | kg lbs |
| Tongue Weight | kg lbs |
| Number of Cylinders | — — |
| Gross Horsepower (Maximum) | kw hp |
| Torque (Max) | Nm ft-lb |
| Fuel Tank Capacity | L gal |
| Max Fuel Consumption | lph gph |
| Fuel Type | — |
| Air Cleaner | — |
| Oil Filter | — |
| Recommended Oil | — |
| Oil Volume with Filter | L qt |
| Maximum Angle of Continuous Operation | — deg |
| Cooling Medium | — |
| Coolant Capacity (Engine and Radiator) | L gal |
| Alternator | — |
| Fan | — |
| Clutch Type | — |
| Clutch Drive Engagement | — |
| Make and Model | — |
|---|---|
| Number of Cylinders | — — |
| Gross Horsepower (Maximum) | kw hp |
| Torque (Max) | Nm ft-lb |
| Fuel Type | — |
| Air Cleaner | — |
| Fuel Tank Capacity | L gal |
| Oil Filter | — |
| Recommended Oil | — |
| Oil Volume with Filter | L qt |
| Cooling Medium | — |
| Coolant Capacity (Engine and Radiator) | L gal |
| Alternator | — |
| Fan | — |
| Clutch Type | — |
| Power | kw hp |
|---|---|
| Voltage | — |
| Phase | — |
| Enclosure | — |
| Full Load Amps | — |
| Full load RPM | — rpm |
| Power | kw hp |
|---|---|
| Voltage | — |
| Phase | — |
| Enclosure | — |
| Full Load Amps | — |
| Full load RPM | — rpm |
| Power | kw hp |
|---|---|
| Voltage | — |
| Phase | — |
| Enclosure | — |
| Full Load Amps | — |
| Full load RPM | — rpm |
| Power | kw hp |
|---|---|
| Voltage | — |
| Phase | — |
| Enclosure | — |
| Full Load Amps | — |
| Full load RPM | — rpm |
| Feed Roller Orientation | Horizontal, offset |
|---|---|
| Number of Feed Rollers | 2 |
| Feed Roller Clamp Load | 307 kg 676.8 lbs |
| Feed Roller Clamp Type | Spring |
| Feed Roller Minimum Distance to Drum | 4.3 cm 1.7 in |
| Feed Roller Dimension | 7.6 in (19.4 cm) |
| Number of Knives | — 8 |
| Weight of Feed Roller | 7.1 kg 15.7 lbs |
| Feed Roller Dimension (Two) | 7.6 in (19.4) |
| Number of Knives (2) | — 8 |
| Weight of Feed Roller (Option Two) | 7.1 kg 15.7 lbs |
| Number of Feed Roller Motors | 2 |
| Motor Displacement | 250 cc |
| Motor Manufacturer | Contarini |
| Feed Speed | — 98.4 ft/min |
| Motor displacement (option two) | — |
| Motor manufacturer (option two) | — |
| Feed speed (option two) | m/min ft/min |
| Infeed Table Width | 109.2 cm 43 in |
| Infeed Table Length | 56.9 cm 22.4 in |
| Infeed Hopper Height | 68.1 cm 26.8 in |
| Infeed Throat Capacity | 6.7 x 7.8 in (170 x 198 mm) |
| Pinch Point - Distance to End of Feed Table | 149.9 cm 59 in |
| Distance from Feed Table to Ground | 76.2 cm 30 in |
| Infeed Table Material Thickness | .2 cm .1 in |
| Bottom Feed Stop Bar | Floating, spring return |
|---|---|
| Bottom Feed Stop Bar Diameter | 2.7 cm 1.1 in |
| Bottom Feed Stop Bar Material Thickness | 0.1 in (2.6 mm) |
| Actuation Force (BFSB) | 17 kg 37.5 lbs |
| Normal Sensitivity | — deg |
| Reduced Sensitivity | — deg |
| Reset Method | Push button |
| Four Position Feed Control Bar | — |
| Diameter | cm in |
| Material Thickness | cm in |
| Positions | — |
| Actuation Force | kg lbs |
| Green Hold to Run Button | — |
| Material Capacity | cm in |
|---|---|
| Width | cm in |
| Thickness | cm in |
| Diameter | cm in |
| Speed | — |
| Weight With Shaft | kg lbs |
| Safety Lock - Number of Positions | 2 |
| Number of Knives | — 2 |
| Knife Thickness | 1.6 cm .6 in |
| Material | A8 Chipper steel |
| Useable Edges | 2 |
| Knife Size | 8 x 5 in (20.3 x 12.7 cm) |
| Number of Bolts/Knife | 3 |
| Replaceable Threaded Knife Block | — |
| Number of Paddles | 2 |
| Fixture Method | Welded |
| Air Flow | — cfm |
| Bedknife Size | 7.2 x 2.8 in (18.4 x 7 cm) |
| Bedknife Thickness | 2 cm .8 in |
| Bedknife Material | Hardox 450 |
| Bedknife - Number of Useable Edges | 2 |
| Number of Bearings | — 2 |
|---|---|
| Bore | 4.1 cm 1.6 in |
| Type | Dual spherical roller, piloted flange housing |
| Manufacturer | Timken |
| Dynamic Capacity | kg lbs |
| Static Capacity | kg lbs |
| Belt Idler/Tensioner | Idler arm, Manually adjusted |
| Belt Type | 2 XPA, quadpower belts |
| Number of Bearings | — — |
|---|---|
| Bore | cm in |
| Type | — |
| Manufacturer | — |
| Dynamic Capacity | kg lbs |
| Static Capacity | kg lbs |
| Belt Idler/Tensioner | — |
| Belt Type | — |
| Number of Bearings | — — |
|---|---|
| Bore | cm in |
| Type | — |
| Manufacturer | — |
| Dynamic Capacity | kg lbs |
| Static Capacity | kg lbs |
| Belt Idler/Tensioner | — |
| Belt Type | — |
| Chute Height | 238 cm 93.7 in |
|---|---|
| Bottom Thickness | .2 cm .1 in |
| Top Thickness | .2 cm .1 in |
| Side Wall Thickness | .2 cm .1 in |
| Deflector Thickness | .2 cm .1 in |
| Chute Rotation Angle | — 270 deg |
| Rotation Type | Manual |
| Rotational Lock | Clamp |
| Tank capacity | 1.5 L .4 gal |
|---|---|
| Recommended Oil Type | Mobil SHC Hydraulic EAL 46 |
| System Type | Fixed flow, Open circuit |
| Filtration Method | Suction: 100 Mesh, Return: 10 Micron |
| Pump Flow at Maximum RPM | 18 L/min 4.8 gpm |
| System relief pressure | 172.4 bar 2500 psi |
| Auto Reverse PSI | 158.6 bar 2300 psi |
| Flow Control | — |
| Directional Control | 12 V solenoid controlled |
| Oil Cooler | — |
| System Voltage | 12 V |
|---|---|
| Battery | 12 V dC, 53 Ah, 540 CCA |
| Standard Gauges | — |
| Deluxe Gauges | — |
| Switches | Pizzato |
| Controller | MPC 12 |
| Display | MPC 12 |
| Shutdown System | Briggs & Stratton ECU |
| Radio Remote Control | — |
| Frame Description | Ladder frame chassis, U-shaped rails |
|---|---|
| Toolbox Description | — |
| Tongue Description | Bolt on, top mount |
| Tongue Extension | — |
| Hitch Type | Alko 90S - 50 mm ball coupler |
| Fender Description | Bolt-on plastic |
| Axle/Suspension | Rubber torsion |
| Type - Option One | Alko 1350 |
| Manufacturer - Option One | Alko |
| Capacity - Option One | 2 980 lbs (1 350 kg) per axle |
| Tires - Option One | 155/70 R12C 104/102 N |
| Wheels - Option One | 4.5Jx12 ET30 67/112/5 |
| Axle/Suspension - Option Two | — |
| Type - Option Two | — |
| Manufacturer - Option Two | — |
| Capacity - Option Two | — |
| Tires - Option Two | — |
| Wheels - Option Two | — |
| Axle/Suspension - Option Three | — |
| Type - Option Three | — |
| Manufacturer - Option Three | — |
| Capacity - Option Three | — |
| Tires - Option Three | — |
| Wheels - Option Three | — |
| Brake Type | 8 x 2 in (200 mm x 50 mm) Drum, surge brake activated |
| Trailer Light Type | LED |
| Track Frame Description | — |
|---|---|
| Track Type | — |
| Track Width | — |
| Track Length on Ground | — |
| Type of Idler | — |
| Number of Idlers | — — |
| Track Drive Pump Type | — |
| Pump Flow at Maximum RPM | — |
| System Relief Pressure | — |
| Track Drive Motor Type | — |
| Track Brake Type | — |
| High Speed Travel | km/h mph |
| Low Speed Travel | km/h mph |
| Ground Bearing Pressure - Soft Ground | kPa psi |
| Ground Bearing Pressure - Hard Ground | kPa psi |
| Length | cm in |
|---|---|
| Width | cm in |
| Height | cm in |
| Weight | kg lbs |
| Winch Relief System | bar psi |
|---|---|
| Winch Boom Structure | — |
| Winch Input Speed | — rpm |
| Winch Controls | — |
| Winch Rope | — |
| Rope Length | m ft |
| Rope Line Pull | kg lbs |
| Rope Choker | — |
| Special Paint | Available |
|---|---|
| Extended Warranty | Available |
| Preventive Maintenance | Available |
| Adjustable Height Discharge Chute | — |
| Hydraulically Engaged Clutch | — |
| Remote Control | — |
| Hydraulic Outriggers | — |
| Hydraulic Chute Controls | — |
| Loader Relief Pressure | bar psi |
|---|---|
| Loader Boom Structure | — |
| Loader Reach | m ft |
| Loader Lift Capacity at Full Reach | kg lbs |
| Loader Maximum Lift Capacity | kg lbs |
| Loader Controls | — |
| Loader Rotation | — |
| Loader Grapple Rotation | — |
| Length - Feed Table Up, Tongue In | cm in |
|---|---|
| Length - Table Down, Tongue Extended | cm in |
| Width | cm in |
| Height | cm in |
| Weight (without winch and hydraulic jack) | kg lbs |
| Weight - Engine Option One | kg lbs |
| Tongue Weight - Engine Option One | kg lbs |
| Distance from Feed Table to Ground | cm in |
| Chute Height | cm in |
| Frame Description | — |
| Hitch Type | — |
| Type - Option One | — |
| Manufacturer - Option One | — |
| Capacity - Option One | — |
| Tires - Option One | — |
| Wheels - Option One | — |
| Length - Feed Table Up, Tongue In | cm in |
|---|---|
| Length - Table Down, Tongue Extended | cm in |
| Width | cm in |
| Height | cm in |
| Weight (without winch and hydraulic jack) | kg lbs |
| Weight - Engine Option One | kg lbs |
| Tongue Weight - Engine Option One | kg lbs |
| Distance from Feed Table to Ground | cm in |
| Chute Height | cm in |
| Frame Description | — |
| Hitch Type | — |
| Type - Option One | — |
| Manufacturer - Option One | — |
| Capacity - Option One | — |
| Tires - Option One | — |
| Wheels - Option One | — |
Video
Modele similare
Toate din Brush Chippers →
CE
BC200 Brush Chipper
The BC200 is built tough to support your daily business and surpass expectations.
- Gross Horsepower (Maximum)
- 33 kw 44.3 hp
CE
BC230 Brush Chipper
The BC230 is built tough to support your daily operations and surpass expectations.
- Gross Horsepower (Maximum)
- 55.2 kw 74 hp
CE
BC1000XL European Configuration Brush Chipper
The heavy-duty Vermeer BC1000XL brush chipper with its all-steel engine enclosure is designed to hold up for the long haul.
- Gross Horsepower (Maximum)
- 55.2 kw 74 hp
