Pe scurt
- Rated Operating Capacity (SAE)
- 353.8 kg 780 lbs
Caracteristici & beneficii
- Efficient performance in a compact footprint
- Improved lift capacity and enhanced hydraulics
- Designed for operator comfort and ease of maintenance
Broșuri & fișe tehnice
Date tehnice
Specificații tehnice
| Length | 213.4 cm 84 in |
|---|---|
| Width (Narrow Tracks) | 91.4 cm 36 in |
| Width (Wide Tracks) | 101.6 cm 40 in |
| Width | cm in |
| Height | 147.3 cm 58 in |
| Hinge Pin Height | 214.6 cm 84.5 in |
| Ground Clearance | 15.2 cm 6 in |
| Weight (Wide Tracks) | 1433.4 kg 3160 lbs |
| Weight | kg lbs |
| Make | Rehlko |
|---|---|
| Model | 1403 KSD-NA |
| Gross Horsepower | 18.4 kw 24.7 hp |
| Fuel Type | Diesel |
| Fuel Tank Capacity | 49.2 L 13 gal |
| Rated Operating Capacity (SAE) | 353.8 kg 780 lbs |
|---|---|
| Ground Pressure (Narrow Tracks) | 33.8 kPa 4.9 psi |
| Ground Pressure (Wide Tracks) | 26.2 kPa 3.8 psi |
| Ground Pressure | kPa psi |
| Max Travel Speed | 6.8 km/h 4.2 mph |
| Steering | Single pilot-operated joystick |
|---|---|
| Lift/Curl | Single pilot-operated joystick |
| Auxiliary High Flow | 45.8 L/min 12.1 gpm |
|---|---|
| Auxiliary Low Flow | 19.7 L/min 5.2 gpm |
| Hydraulic System Pressure | 209.9 bar 3045 psi |
| Tank Fill Capacity | 33.7 L 8.9 gal |
