Pe scurt
- Gross Horsepower (Maximum)
- 18.6 kw 25 hp
Caracteristici & beneficii
- A compact footprint for maneuverability and access
- Designed with ease of maintenance in mind
- Safety-focused design
Broșuri & fișe tehnice
Date tehnice
Specificații tehnice
| Length - Tongue In | cm in |
|---|---|
| Length - Tongue Extended | cm in |
| Length | 238.8 cm 94 in |
| Width | 88.9 cm 35 in |
| Width (tracks retracted) | cm in |
| Width (tracks extended) | cm in |
| Height | 124.5 cm 49 in |
| Height (non-remote unit) | cm in |
| Height (remote unit) | cm in |
| Overall Width Transport (without duals) | cm in |
| Overall Width Transport (with duals) | cm in |
| Overall Height Transport | cm in |
| Overall Height Transport - Engine Option Two | cm in |
| Weight - Engine Option One | 703.1 kg 1550 lbs |
| Weight - Engine Option Two | kg lbs |
| Weight - Engine Option Three | kg lbs |
| Tongue Weight - Engine Option One | kg lbs |
| Tongue Weight - Engine Option Two | kg lbs |
| Tongue Weight - Engine Option Three | kg lbs |
| Weight With Dual Wheel Option (Additional ) | kg lbs |
| Width with Dual Wheel Option (Additional) | cm in |
| Weight with Four Wheel Drive and Chip Blade (Additional) | kg lbs |
| Weight With Chip Blade Option (Additional) | kg lbs |
| Sound Power | — |
| Sound Power - Engine Option Two | — |
| Sound Power - Engine Option Three | — |
| Make and Model | Kohler ECH740 |
|---|---|
| Number of Cylinders | — 2 |
| Gross Horsepower (Maximum) | 18.6 kw 25 hp |
| Torque (Max) | 56.9 Nm 42 ft-lb |
| Fuel Tank Capacity | 25.7 L 6.8 gal |
| Max Fuel Consumption | 9.1 lph 2.4 gph |
| Fuel Type | Gas |
| Air Cleaner | 6 " (15.2 cm) 2-Stage dry |
| Oil Filter | Spin-on |
| Recommended Oil | Kohler oil or API CH4/SJ |
| Oil Volume with Filter | 1.9 L 2 qt |
| Maximum Angle of Continuous Operation | — 25 deg |
| Cooling Medium | Air/oil |
| Coolant Capacity (Engine and Radiator) | L gal |
| Alternator | — |
| Fan | — |
| Clutch Type | — |
| Make and Model | — |
|---|---|
| Number of Cylinders | — — |
| Gross Horsepower (Maximum) | kw hp |
| Torque (Max) | Nm ft-lb |
| Fuel Tank Capacity | L gal |
| Max Fuel Consumption | lph gph |
| Fuel Type | — |
| Air Cleaner | — |
| Oil Filter | — |
| Recommended Oil | — |
| Oil Volume with Filter | L qt |
| Maximum Angle of Continuous Operation | — deg |
| Cooling Medium | — |
| Coolant Capacity (Engine and Radiator) | L gal |
| Alternator | — |
| Fan | — |
| Clutch Type | — |
| Make and Model | — |
|---|---|
| Number of Cylinders | — — |
| Gross Horsepower (Maximum) | kw hp |
| Torque (Max) | Nm ft-lb |
| Fuel Tank Capacity | L gal |
| Max Fuel Consumption | lph gph |
| Fuel Type | — |
| Air Cleaner | — |
| Oil Filter | — |
| Recommended Oil | — |
| Oil Volume with Filter | L qt |
| Maximum Angle of Continuous Operation | — deg |
| Cooling Medium | — |
| Coolant Capacity (Engine and Radiator) | L gal |
| Alternator | — |
| Fan | — |
| Clutch Type | — |
| Clutch Drive Engagement | — |
| Cutterwheel Diameter | 40.6 cm 16 in |
|---|---|
| Cutterwheel Diameter without Teeth | cm in |
| Cutterwheel Thickness | 1.3 cm .5 in |
| Cutterwheel Speed | — 1110 rpm |
| Cutterwheel Straight Line Dimension | 90.2 cm 35.5 in |
| Cutterwheel Cut Above Ground | 63.5 cm 25 in |
| Cutterwheel Cut Below Ground | 30.5 cm 12 in |
| Tooth Description | Yellow Jacket Cutter System |
| Number of Teeth | 16 |
| Number of Indexes | 2 |
| Number of Pockets | 16 |
| Number of wear plates | — |
| Reversible Pockets/Teeth | Yes |
| Cutterwheel Guard | Yes |
| Chip Containment | .1 cu m 2.2 cu ft |
| Cutterwheel Diameter without Teeth | cm in |
|---|---|
| Cutterwheel Thickness | cm in |
| Cutterwheel Speed | — rpm |
| Cutterwheel Straight Line Dimension | cm in |
| Cutterwheel Cut Above Ground | cm in |
| Cutterwheel Cut Below Ground | cm in |
| Tooth Description | — |
| Number of Teeth | 20 |
| Cutterwheel Guard | — |
| Number of Indexes | — |
| Number of Pockets | — |
| Reversible Pockets/Teeth | — |
| Chip Containment | cu m cu ft |
| Upper Gearbox | — |
|---|---|
| Oil Type | — |
| Oil Capacity | L qt |
| Lower Gearbox | Hydraulic motor |
| Oil Type - Lower Gearbox | — |
| Oil Capacity - Lower Gearbox | L qt |
| Driveshaft | — |
| Driveshaft - U Joints | — |
| Belt Type | — |
| Number of Primary Belts | — |
| Jackshaft Dimension | — |
| Jackshaft Bearing Type | — |
| Bearing Dimensions | — |
| Dynamic Capacity | kg lbs |
| Number of Secondary Belts | — |
| Cutterwheel Shaft | — |
| Bearing Dimensions - Secondary Belt | — |
| Dynamic Capacity - Secondary Belt | kg lbs |
| Tank capacity | 34.1 L 9 gal |
|---|---|
| Recommended Oil Type | ISO 68 |
| System Type | Open loop |
| Filtration Method | Inline return filter |
| Pump Flow at Maximum RPM | 60.6 L/min 16 gpm |
| System relief pressure | 189.6 bar 2750 psi |
| Flow Control | Autosweep (option) |
| Directional Control | Standard |
| Oil Cooler | Yes. Fan-cooled |
| Tank capacity | L gal |
|---|---|
| Recommended Oil Type | — |
| System Type | — |
| Filtration Method | — |
| Pump Flow at Maximum RPM | L/min gpm |
| System relief pressure | bar psi |
| Flow Control | — |
| Directional Control | — |
| Oil Cooler | — |
| System Voltage | 12 |
|---|---|
| Battery | 405 |
| Standard Gauges | Hour meter/tach |
| Deluxe Gauges | — |
| Warning Lights | — |
| Switches | Cutter wheel drive |
| Controller | Yes |
| Display | — |
| Shutdown System | — |
| Radio Remote Control | — |
| Frame Description | — |
|---|---|
| Control Station Description | Fixed-rear |
| Operator Vision Shield Description | — |
| Toolbox Description | — |
| Tongue Description | — |
| Tongue Extension | — |
| Hitch Type | — |
| Steerable Axle Type | — |
| Degree of Oscillation | — deg |
| Turning Radius | — deg |
| Tires - Option One | — |
| Wheels - Option One | — |
| Fender Description | — |
| Axle/Suspension | — |
| Type - Option One | — |
| Manufacturer - Option One | — |
| Capacity - Option One | — |
| Tires - Standard | — |
| Tires - Floatation | — |
| Wheels - Standard | — |
| Wheels - Floatation | — |
| Brake Type | — |
| Trailer Light Type | — |
| Track Frame Description | — |
|---|---|
| Track Type | Rubber 7 " (17.8 cm) width |
| Track Width - Retracted | 35 " (88.9 cm) |
| Track Width - Extended | 35 " (88.9 cm) |
| Track Length on Ground | 31.4 " (79.7 cm) |
| Type of Idler | Cast |
| Number of Idlers | — 5 |
| Track Drive Pump Type | Hydrostatic |
| System Relief Pressure | 2900 psi (200 bar) |
| Pump Flow at Maximum RPM | 11.4 gpm (43.1 L/min) |
| Track Drive Motor Type | Geroter |
| Track Brake Type | Hydrostatic |
| High Speed Travel | 5.1 km/h 3.2 mph |
| Low Speed Travel with Boost Assist | km/h mph |
| Low Speed Travel | km/h mph |
| Low Speed Travel in Creep Mode | km/h mph |
| Ground Bearing Pressure - Soft Ground | 23.4 kPa 3.4 psi |
| Ground Bearing Pressure - Hard Ground | kPa psi |
| Low Speed Travel | m/min ft/min |
|---|---|
| Low Speed Travel - Engine Option Two | m/min ft/min |
| High Speed Travel | m/min ft/min |
| High Speed Travel - Engine Option Two | m/min ft/min |
| Chip Blade Dimension | — |
|---|---|
| Chip blade width (without extensions) | cm in |
| Blade Travel Above Ground | cm in |
| Blade Travel Below Ground | cm in |
| Bumper | — |
| Radio Remote Control | — |
|---|---|
| Remote Functions | — |
| Remote Display | — |
| Remote Range | — |
| Special Paint | Per request |
|---|---|
| Extended Warranty | Per request |
| Preventive Maintenance | Per request |
| Hydraulically Engaged Clutch | — |
| Description | — |
|---|---|
| Sensor Type | — |
| Quantity/Location | — |
| Visual Interface | — |
