Vermeer
⤢ Mărește
Pe scurt
- Gross Horsepower (Maximum)
- 41.8 kw 56 hp
Caracteristici & beneficii
- Impressive cutting dimensions
- Powerful performance at the stump
- Standard features for the stump grinding professional
Broșuri & fișe tehnice
Date tehnice
Specificații tehnice
| Length - Tongue In | cm in |
|---|---|
| Length - Tongue Extended | cm in |
| Length | 373.4 cm 147 in |
| Width | 88.9 cm 35 in |
| Width (tracks retracted) | cm in |
| Width (tracks extended) | cm in |
| Height | 194.3 cm 76.5 in |
| Height (non-remote unit) | cm in |
| Height (remote unit) | cm in |
| Overall Width Transport (without duals) | cm in |
| Overall Width Transport (with duals) | cm in |
| Overall Height Transport | cm in |
| Overall Height Transport - Engine Option Two | cm in |
| Weight - Engine Option One | 1814.4 kg 4000 lbs |
| Weight - Engine Option Two | kg lbs |
| Weight - Engine Option Three | kg lbs |
| Tongue Weight - Engine Option One | kg lbs |
| Tongue Weight - Engine Option Two | kg lbs |
| Tongue Weight - Engine Option Three | kg lbs |
| Weight With Dual Wheel Option (Additional ) | kg lbs |
| Width with Dual Wheel Option (Additional) | 142.2 cm 56 in |
| Weight with Four Wheel Drive and Chip Blade (Additional) | kg lbs |
| Weight With Chip Blade Option (Additional) | kg lbs |
| Sound Power | — |
| Sound Power - Engine Option Two | — |
| Sound Power - Engine Option Three | — |
| Make and Model | Kohler KDI 1903 |
|---|---|
| Number of Cylinders | — 3 |
| Gross Horsepower (Maximum) | 41.8 kw 56 hp |
| Torque (Max) | 223.7 Nm 165 ft-lb |
| Fuel Tank Capacity | 54.9 L 14.5 gal |
| Max Fuel Consumption | 9.2 lph 2.4 gph |
| Fuel Type | Diesel |
| Air Cleaner | Dry type safety element and restriction indicator |
| Oil Filter | Cartridge Style |
| Recommended Oil | SAE 10W30 Low SAPS - ACEA E6-E9 |
| Oil Volume with Filter | 8.9 L 9.4 qt |
| Maximum Angle of Continuous Operation | — 30 deg |
| Cooling Medium | Liquid |
| Coolant Capacity (Engine and Radiator) | 6.2 L 1.7 gal |
| Alternator | 100 amp |
| Fan | Suction |
| Clutch Type | Hydrostatic Transmission |
| Make and Model | — |
|---|---|
| Number of Cylinders | — — |
| Gross Horsepower (Maximum) | kw hp |
| Torque (Max) | Nm ft-lb |
| Fuel Tank Capacity | L gal |
| Max Fuel Consumption | lph gph |
| Fuel Type | — |
| Air Cleaner | — |
| Oil Filter | — |
| Recommended Oil | — |
| Oil Volume with Filter | L qt |
| Maximum Angle of Continuous Operation | — deg |
| Cooling Medium | — |
| Coolant Capacity (Engine and Radiator) | L gal |
| Alternator | — |
| Fan | — |
| Clutch Type | — |
| Make and Model | — |
|---|---|
| Number of Cylinders | — — |
| Gross Horsepower (Maximum) | kw hp |
| Torque (Max) | Nm ft-lb |
| Fuel Tank Capacity | L gal |
| Max Fuel Consumption | lph gph |
| Fuel Type | — |
| Air Cleaner | — |
| Oil Filter | — |
| Recommended Oil | — |
| Oil Volume with Filter | L qt |
| Maximum Angle of Continuous Operation | — deg |
| Cooling Medium | — |
| Coolant Capacity (Engine and Radiator) | L gal |
| Alternator | — |
| Fan | — |
| Clutch Type | — |
| Clutch Drive Engagement | — |
| Cutterwheel Diameter | 58.4 cm 23 in |
|---|---|
| Cutterwheel Diameter without Teeth | cm in |
| Cutterwheel Thickness | 2.9 cm 1.1 in |
| Cutterwheel Speed | — 1124 rpm |
| Cutterwheel Straight Line Dimension | 182.9 cm 72 in |
| Cutterwheel Cut Above Ground | 78.7 cm 31 in |
| Cutterwheel Cut Below Ground | 63.5 cm 25 in |
| Tooth Description | Yellow Jacket Cutting System |
| Number of Teeth | 26 |
| Number of Indexes | 2 per tooth |
| Number of Pockets | 26 |
| Number of wear plates | — |
| Reversible Pockets/Teeth | Yes- standard |
| Cutterwheel Guard | Standard |
| Chip Containment | .8 cu m 28.2 cu ft |
| Cutterwheel Diameter without Teeth | cm in |
|---|---|
| Cutterwheel Thickness | cm in |
| Cutterwheel Speed | — rpm |
| Cutterwheel Straight Line Dimension | cm in |
| Cutterwheel Cut Above Ground | cm in |
| Cutterwheel Cut Below Ground | cm in |
| Tooth Description | — |
| Number of Teeth | — |
| Cutterwheel Guard | — |
| Number of Indexes | — |
| Number of Pockets | — |
| Reversible Pockets/Teeth | — |
| Chip Containment | cu m cu ft |
| Upper Gearbox | — |
|---|---|
| Oil Type | — |
| Oil Capacity | L qt |
| Lower Gearbox | 90 degree |
| Oil Type - Lower Gearbox | Syn 75W90 |
| Oil Capacity - Lower Gearbox | 1.5 L 1.6 qt |
| Driveshaft | Standard |
| Driveshaft - U Joints | 2 standard with double lip seals |
| Belt Type | — |
| Number of Primary Belts | — |
| Jackshaft Dimension | — |
| Jackshaft Bearing Type | — |
| Bearing Dimensions | — |
| Dynamic Capacity | kg lbs |
| Number of Secondary Belts | — |
| Cutterwheel Shaft | — |
| Bearing Dimensions - Secondary Belt | — |
| Dynamic Capacity - Secondary Belt | kg lbs |
| Tank capacity | 64.4 L 17 gal |
|---|---|
| Recommended Oil Type | Vermeer HyPower 68 |
| System Type | 2 closed loops and 1 open |
| Filtration Method | Suction strainers, one charge pump filter and one 3 micron return filter |
| Pump Flow at Maximum RPM | L/min gpm |
| System relief pressure | bar psi |
| Flow Control | — |
| Directional Control | Electric over hydraulic |
| Oil Cooler | Standard |
| Tank capacity | L gal |
|---|---|
| Recommended Oil Type | — |
| System Type | — |
| Filtration Method | — |
| Pump Flow at Maximum RPM | L/min gpm |
| System relief pressure | bar psi |
| Flow Control | — |
| Directional Control | — |
| Oil Cooler | — |
| System Voltage | 12 Volt |
|---|---|
| Battery | 950 CCA |
| Standard Gauges | — |
| Deluxe Gauges | DP05 Display - Fuel,Hour Meter, Selectible |
| Warning Lights | Low oil pressure, high engine temperature, alternator/charging, wait to start glow plug indicator, high and low hydraulic temp, ACS controller function lights- various functions shown on controller |
| Switches | Two-speed ground drive, blade, steering, differential propel lock, SmartSweep settings, cutterwheel engage/disengage, creep, propel system joystick and boom controls joystick |
| Controller | Vermeer ACS |
| Display | — |
| Shutdown System | High coolant temperature, low oil pressure and high hydraulic oil temperature |
| Radio Remote Control | Functions include: propel forward/reverse; boom up/down, boom left/right, steering left/right, blade up/down, SmartSweep settings, travel speed high/low, differential lock, throttle |
| Frame Description | Welded tube and plate steel |
|---|---|
| Control Station Description | Swing out control station with three available positions plus auxiliary control station |
| Operator Vision Shield Description | Abrasion resistant coated polycarbonate, 3/16" thick |
| Toolbox Description | Standard |
| Tongue Description | — |
| Tongue Extension | — |
| Hitch Type | — |
| Steerable Axle Type | Two wheels, hydraulic |
| Degree of Oscillation | — 15 deg |
| Turning Radius | — 105 deg |
| Tires - Option One | — |
| Wheels - Option One | — |
| Fender Description | — |
| Axle/Suspension | Steerable axle type |
| Type - Option One | — |
| Manufacturer - Option One | — |
| Capacity - Option One | — |
| Tires - Standard | Rear:Duals, 23x8.5-14 |
| Tires - Floatation | — |
| Wheels - Standard | Rear: 14" x 6" (35.56 cm x 15.24 cm) |
| Wheels - Floatation | — |
| Brake Type | Spring applied, hydraulic release at planetary drives and hydrostatic braking (closed loop) |
| Trailer Light Type | — |
| Track Frame Description | — |
|---|---|
| Track Type | — |
| Track Width - Retracted | — |
| Track Width - Extended | — |
| Track Length on Ground | — |
| Type of Idler | — |
| Number of Idlers | — — |
| Track Drive Pump Type | — |
| System Relief Pressure | — |
| Pump Flow at Maximum RPM | — |
| Track Drive Motor Type | — |
| Track Brake Type | — |
| High Speed Travel | km/h mph |
| Low Speed Travel with Boost Assist | km/h mph |
| Low Speed Travel | km/h mph |
| Low Speed Travel in Creep Mode | km/h mph |
| Ground Bearing Pressure - Soft Ground | kPa psi |
| Ground Bearing Pressure - Hard Ground | kPa psi |
| Low Speed Travel | m/min ft/min |
|---|---|
| Low Speed Travel - Engine Option Two | m/min ft/min |
| High Speed Travel | m/min ft/min |
| High Speed Travel - Engine Option Two | m/min ft/min |
| Chip Blade Dimension | Standard - 34 inches wide, 13.75 inches tall |
|---|---|
| Chip blade width (without extensions) | cm in |
| Blade Travel Above Ground | 35.6 cm 14 in |
| Blade Travel Below Ground | cm in |
| Bumper | .75" (1.9 cm) plate |
| Radio Remote Control | Optional |
|---|---|
| Remote Functions | Engine stop, throttle, cutter wheel engage, swing, raise/lower, propel, creep, smartsweep |
| Remote Display | LED |
| Remote Range | 300' |
| Special Paint | Optional |
|---|---|
| Extended Warranty | 2 years/ 2000 hours or 3 years/3000 hours |
| Preventive Maintenance | Optional |
| Hydraulically Engaged Clutch | — |
| Description | Capacitive Handles - Swing/Raise & Lower |
|---|---|
| Sensor Type | Capacitive Handles |
| Quantity/Location | 2 - Swing Out Station |
| Visual Interface | Indicator Light/Display |
